The PERAFLEX Layflat Water Discharge Hose 10 Bar is a lightweight softwall rubber discharge hose widely used across Malaysia for industrial waste water discharge, pump discharge, and mobile irrigation systems. Its layflat design means the hose lies completely flat when not pressurised — allowing compact coiling, easy storage, and rapid deployment over long distances on construction sites, agricultural land, and flood emergency situations. When pressurised, the bore opens fully for maximum flow efficiency. Rated at 10 Bar (145 PSI) with a 3:1 safety factor. Available from Flytech Engineering Sdn Bhd with ready stock in Klang, Selangor — Malaysia’s trusted industrial rubber hose supplier since 1999.
Key Features
• Working Pressure: 10 Bar (145 PSI) — suitable for pump discharge and pressurised water transfer
• Burst Pressure: 30 Bar (435 PSI) — 3:1 safety factor
• Layflat design — completely flat when empty for compact storage and transport
• Full-bore opening under pressure — maximum flow efficiency with no restriction
• Lightweight construction — easy to carry, deploy and recover on site
• Temperature Range: -20°C to +70°C
• Tube: Black SBR/NR rubber — smooth bore for maximum water flow
• Reinforcement: High-strength synthetic textile braid
• Cover: Black EPDM blend — abrasion, weather and ozone resistant for outdoor Malaysian conditions
• PERAFLEX branded — ISO 9001:2015 certified quality
Applications
• Industrial waste water and effluent discharge from submersible pumps in Malaysian factories
• Mobile irrigation discharge in palm oil, rubber and vegetable plantations across Malaysia
• Construction site dewatering discharge — temporary pipelines on Klang Valley and Johor projects
• Flood emergency water discharge during monsoon season across Malaysia
• Temporary water supply pipelines on construction and civil engineering sites
• Mining and quarry site water discharge in Perak, Pahang, Sabah and Sarawak
• Fire brigade and BOMBA auxiliary water supply deployment
Available Configurations
• Loose hose — cut to required length at Flytech Engineering Klang
• Assembled with Camlock couplings — fast tool-free connection between hose sections
• Assembled with BSP threaded end fittings
• Available in large diameter sizes for high-volume flow requirements
• Fast nationwide delivery from Klang to all Malaysian states and Singapore
Why Choose Flytech Engineering?
• Ready stock in Klang, Selangor — same-day dispatch to Kuala Lumpur, Shah Alam, Johor Bahru, Penang, Ipoh, Kerteh, Kemaman and all Malaysian states
• ISO 9001:2015 certified manufacturer and supplier — consistent quality since 1999
• PERAFLEX brand — trusted industrial rubber hose manufactured and distributed by Flytech Engineering
• In-house hydrostatic pressure testing with official test certificates issued
• Custom hose assembly — cut to length, end fittings crimped and fitted same day
• Over 27 years supplying 2,000+ clients in Malaysia including GLCs, GLICs, oil & gas companies and major manufacturers
• Branches in Klang (HQ), Butterworth Penang, and Singapore — serving Malaysia and worldwide
Frequently Asked Questions
Q: What is layflat hose used for in Malaysia?
A: Layflat hose in Malaysia is used for water discharge, pump discharge, mobile irrigation, flood drainage, and temporary water supply. The layflat design allows the hose to be rapidly deployed over long distances on construction sites, agricultural land, and during flood emergencies. Common users include construction companies, plantation operators, mining companies, and BOMBA (Malaysian Fire and Rescue Department). PERAFLEX Layflat Water Discharge Hose 10 Bar is available from Flytech Engineering in Klang.
Q: What is the difference between layflat 5 Bar and 10 Bar discharge hose?
A: PERAFLEX Layflat Water Discharge Hose 10 Bar is designed for pump discharge applications where the pump output pressure can reach up to 10 Bar. The 5 Bar version is for low-pressure gravity-fed systems and low-pressure pump discharge. Choose 10 Bar for industrial pump discharge in construction dewatering and factory effluent systems. Choose 5 Bar for agricultural irrigation and gravity drainage.
Q: Where can I buy layflat hose in Malaysia?
A: Layflat hose is available from Flytech Engineering Sdn Bhd with ready stock in Klang, Selangor. We supply PERAFLEX Layflat Water Discharge Hose to construction companies, plantation operators, mining companies, and industrial facilities across Malaysia. Contact us at +603-3373 2228 or WhatsApp +6011-1663 3386. We deliver to all Malaysian states and Singapore.
Q: What couplings are used with layflat water discharge hose?
A: PERAFLEX Layflat Water Discharge Hose is most commonly assembled with Camlock couplings for fast, tool-free connection between hose sections and pump outlets. BSP threaded fittings are also available. Flytech Engineering provides same-day hose assembly and coupling fitment at our Klang, Selangor facility.
