Teflon PTFE Conductive Hose (Anti-Static)

Teflon PTFE Conductive Hose (Anti-Static)
PTFE conductive hose anti-static from Flytech Engineering Sdn Bhd is a specialist flexible transfer hose engineered for the safe handling of flammable chemicals, solvents, and volatile fluids in EX classified hazardous areas. PTFE conductive hose anti-static features a carbon black-filled conductive PTFE inner tube — providing static charge dissipation (surface resistance < 10⁶ Ohm) to prevent spark generation during transfer of flammable substances. SS316 wire braid with conductive end connections ensures full electrical continuity throughout the assembly — meeting EN 13463 and ATEX requirements. Temperature rated -60°C to +260°C. Available with ready stock in Klang, Selangor from Flytech Engineering Sdn Bhd — ISO 9001:2015 certified, supplying specialist PTFE hoses since 1999.

Key Features
• Inner tube: Carbon black conductive PTFE — static charge dissipating
• Surface resistance: < 10⁶ Ohm — meets EN 13463 anti-static requirement
• Temperature range: -60°C to +260°C
• Braid: SS316 stainless steel wire braid with conductive end connections
• Full electrical continuity throughout assembly — earthing required
• Suitable for EX hazardous area and ATEX installations
• Near-universal chemical resistance — conductive PTFE inner tube
• Working pressure: Up to 103 Bar (1500 PSI) depending on bore size
• Bore sizes: 6mm to 51mm (1/4″ to 2″)
• Available in smooth bore or convoluted bore construction

Applications
• Flammable solvent transfer in EX classified hazardous areas
• Petrochemical — volatile chemical and solvent loading and unloading
• Paint and coating manufacturing — flammable solvent supply lines
• Pharmaceutical — flammable API, solvent, and reagent transfer
• Oil & gas — volatile hydrocarbon and condensate transfer
• Chemical plant — flammable chemical loading arms and transfer lines
• Semiconductor — flammable process chemical supply connections
• Fuel transfer — aviation fuel, specialty fuel, and racing fuel systems

Available Configurations
• Loose hose — cut to required length
• Assembled with BSP threaded end fittings (SS304 or SS316)
• Assembled with NPT threaded end fittings
• Assembled with JIC 37° end fittings
• Assembled with flanged ends (ANSI 150#, DIN, JIS)
• Sanitary tri-clamp fittings available (SS316)
• Hydrotest with certificate available on request

Why Choose Flytech Engineering for PTFE Hose?
• Ready stock PTFE conductive anti-static hose — Klang, Selangor
• ISO 9001:2015 certified — consistent quality since 1999
• Surface resistance < 10⁶ Ohm — EN 13463 and ATEX compliant
• Full electrical continuity — SS316 braid with conductive end fittings
• Near-universal chemical resistance — safe for all flammable solvents
• Technical support — hazardous area PTFE hose selection and compliance advice
• Over 25 years supplying specialist and hazardous area hoses in Malaysia

Frequently Asked Questions
Q: What is PTFE conductive hose anti-static used for?
A: PTFE conductive hose anti-static is used for the safe transfer of flammable chemicals, solvents, and volatile fluids in EX classified hazardous areas. The carbon black conductive PTFE inner tube dissipates static charges that build up during fluid transfer — preventing spark generation and explosion risk in ATEX zones. Commonly used in petrochemical, pharmaceutical, paint manufacturing, and oil & gas industries.

Q: Why is anti-static PTFE hose required for flammable chemical transfer?
A: Standard PTFE is electrically non-conductive — static charges accumulate during fluid transfer, creating spark and explosion risk with flammable fluids. PTFE conductive hose anti-static uses carbon black-filled PTFE with surface resistance < 10⁶ Ohm — safely dissipating static charges to earth. It is essential for flammable solvent and volatile chemical transfer in EX classified hazardous areas under ATEX regulations.

Q: Is PTFE conductive hose anti-static EN 13463 and ATEX compliant?
A: Yes. PTFE conductive hose anti-static with SS316 braid and conductive end connections provides full electrical continuity with surface resistance < 10⁶ Ohm — meeting EN 13463 requirements for static dissipative hoses in EX classified hazardous areas. Earth bonding of the hose assembly to ground is required during operation. Contact Flytech Engineering for specific ATEX zone compliance confirmation.

Q: What flammable chemicals is PTFE conductive anti-static hose compatible with?
A: The carbon black conductive PTFE inner tube maintains near-universal chemical resistance — compatible with acetone, MEK, toluene, IPA, ethanol, xylene, hexane, ethyl acetate, and virtually all flammable solvents and volatile chemicals used in pharmaceutical, paint, and chemical manufacturing. PTFE conductive hose anti-static from Flytech Engineering is suitable for the most demanding hazardous area chemical transfer applications.

Q: Where can I buy PTFE conductive anti-static hose in Malaysia?
A: PTFE conductive hose anti-static is available with ready stock from Flytech Engineering Sdn Bhd in Klang, Selangor, Malaysia. We supply PTFE conductive anti-static hose with SS316 braid and conductive end fittings — cut to length with BSP, NPT, JIC, and flanged connections. Contact Flytech Engineering for pricing, specifications, and compliance documentation.
