The PERAFLEX Air Hose 20 Bar is a heavy-duty industrial rubber air hose engineered for compressed air supply and pneumatic tool applications. Rated at 20 Bar (300 PSI) working pressure with a 3:1 safety factor, this air hose 20 Bar features a black NBR blend tube resistant to oil mist and a black EPDM blend cover providing abrasion, ozone, and weather resistance for long service life in demanding industrial environments. High tensile synthetic yarn reinforcement ensures pressure stability across the full size range. Available from Flytech Engineering Sdn Bhd with ready stock in Klang, Selangor.
Key Features
• Working Pressure: 20 Bar (300 PSI)
• Burst Pressure: 60 Bar (870 PSI)
• Safety Factor: 3:1
• Tube: Black NBR blend compound — oil mist and compressed air resistant
• Cover: Black EPDM blend compound — abrasion, ozone and weather resistant
• Reinforcement: High tensile synthetic yarn
• Temperature Range: -20°C to +80°C
• Sizes Available: 1/4″ to 2″ (6.4mm to 51mm bore)
• Standard Length: 100m coil (custom lengths available)
• PERAFLEX branded — black printing on cover
Applications
• Compressed air supply to pneumatic tools — drills, grinders, impact wrenches
• General industrial air supply lines in manufacturing and assembly plants
• Construction sites — air compressor connections and tool supply
• Workshop and maintenance air supply systems
• Compressed air transfer in oil & gas, petrochemical, and marine environments
• Pneumatic conveying systems — air supply lines
• Agricultural equipment — pneumatic seeding and spraying systems
Available Configurations
• Loose hose — cut to required length
• Assembled with BSP threaded end fittings
• Assembled with quick release couplings (various types)
• Assembled with Camlock couplings (Type A-F)
• Custom lengths available — same-day assembly for stock sizes
Why Choose Flytech Engineering for PERAFLEX Air Hose?
• Ready stock — Klang, Selangor — fast nationwide delivery
• ISO 9001:2015 certified — consistent quality since 1999
• PERAFLEX brand — trusted industrial rubber hose range
• Custom assembly — cut to length, end fittings same day
• Technical support — hose selection and pressure rating advice
• Over 27 years supplying rubber hoses in Malaysia and worldwide
Frequently Asked Questions
Q: What is PERAFLEX Air Hose 20 Bar used for?
A: PERAFLEX Air Hose 20 Bar is used for compressed air supply to pneumatic tools, general industrial air lines, and workshop air systems. Rated at 20 Bar (300 PSI) working pressure, it is suitable for air drills, grinders, impact wrenches, pneumatic conveyors, and general compressed air applications in manufacturing, construction, oil & gas, and marine industries.
Q: What is the working pressure of PERAFLEX Air Hose 20 Bar?
A: The PERAFLEX Air Hose 20 Bar has a working pressure of 20 Bar (300 PSI) with a burst pressure of 60 Bar (870 PSI) — maintaining a 3:1 safety factor throughout the size range. Suitable for all standard compressed air applications up to 20 Bar.
Q: What sizes are available for PERAFLEX Air Hose 20 Bar?
A: PERAFLEX Air Hose 20 Bar is available in bore sizes from 1/4″ (6.4mm) to 2″ (51mm) with ready stock at Flytech Engineering in Klang, Selangor. Standard length is 100m coil. Custom cut lengths and end fittings available on request.
Q: What temperature range does the air hose handle?
A: PERAFLEX Air Hose 20 Bar is rated from -20°C to +80°C — suitable for all standard industrial compressed air applications including outdoor construction, indoor manufacturing, and air-conditioned environments.
Q: What end fittings are available for air hose?
A: Available assembled with BSP threaded fittings, quick release couplings, and Camlock couplings. Cut to length and fitted at our Klang facility — same-day assembly available for standard sizes in stock.
