Composite Hose SS-Type
The Composite Hose SS Type features stainless steel 316 (SS316) inner and outer wire helixes with polypropylene composite construction — providing superior corrosion resistance compared to galvanised wire hoses. Ideal for aggressive chemical service, marine chemical transfer, and applications where wire corrosion is a concern. This composite hose SS type is EN 13765 certified and compliant with IMO IBC Code. Available from Flytech Engineering Sdn Bhd with ready stock in Klang, Selangor.
Key Features
• Working pressure: 10 Bar (145 PSI)
• Vacuum rating: Full vacuum rated
• Temperature range: -30°C to +80°C
• Inner construction: Polypropylene (PP) tubes, films and fabrics
• Wire: Stainless Steel 316 (SS316) inner and outer wire helix
• Cover: PVC-coated polyester — weatherproof and abrasion resistant
• Sizes: 1″ to 8″ (DN25 to DN200)
• Certification: EN 13765, IMO IBC Code
• Safety factor: 5:1
Applications
• Aggressive chemical suction and discharge
• Marine chemical transfer — ship-to-shore
• Chemical processing plant transfer lines
• Corrosive fluid handling in offshore environments
• Port terminal chemical loading and unloading
• Acids, alkalis, and solvent transfer (selected grades)
Available Configurations
• Loose hose — cut to required length
• Assembled with Camlock couplings (Type A, B, C, D, E, F)
• Assembled with BSP threaded end fittings
• Assembled with flanged ends (ANSI 150#, DIN, JIS)
• Hydrotest with certificate available on request
Why Choose Flytech Engineering?
• Ready stock — Klang, Selangor — fast delivery nationwide
• ISO 9001:2015 certified — consistent quality since 1999
• Over 25 years supplying composite hoses
• Custom assembly — any length, any end fitting
• Hydrotest with cert — for marine, offshore and oil & gas
• Export ready — Singapore, Indonesia, Thailand, Middle East
Frequently Asked Questions
Q: What is composite hose SS type used for?
A: Composite hose SS type is used for aggressive chemical transfer requiring stainless steel wire construction. Suitable for corrosive chemicals, marine environments, ship-to-shore chemical transfer, and offshore chemical handling where galvanised wire would corrode.
Q: What is the difference between composite hose SS and GG type?
A: The SS type uses SS316 wire throughout for maximum corrosion resistance. The GG type uses galvanised steel wire for hydrocarbon and general chemical service. Choose SS type for aggressive chemicals and saltwater marine environments.
Q: Is composite hose SS type suitable for offshore use?
A: Yes. The SS316 wire construction provides excellent resistance to saltwater corrosion — widely used in port terminals and offshore environments.
Q: What sizes are available?
A: Available in sizes 1″ to 8″ (DN25 to DN200) with ready stock for standard sizes. Custom lengths available on request.
Q: Is hydrotest certification available?
A: Yes. Hydrotest with certificate available for all composite hose SS type assemblies — required for chemical plant, marine, and offshore compliance.
